Send InquiryBELIMO NMV-D3-MP Damper Actuator
Price 7800 INR/ Unit
MOQ : 1 Unit
BELIMO NMV-D3-MP Damper Actuator Specification
- Humidity %
- 95% RH non-condensing
- Mounting Type
- Direct shaft mounting
- Shape
- Rectangular
- Feature
- Non-spring return, Modulating, MP-Bus Communication
- IP Rating
- IP54
- Overheating Protection
- Electronic motor overload protection
- Efficiency
- High
- Surface Finish
- Powder Coated
- Insulation Material
- Class III (low voltage)
- Operating Temperature
- -30C to +50C
- Connector Type
- Prewired cable 1m
- Product Type
- Damper Actuator
- Application
- Industrial
- Protection Level
- IP54
- Frequency (MHz)
- 50/60 Hz
- Rated Voltage
- AC/DC 24 V
- Energy Consumption
- 2.5 W (at holding)
- Output Type
- Rotary
- Color
- Orange
- Dimension (L*W*H)
- 164 x 80 x 63 mm
- Weight
- 1.7 kg
- Size
- NMV
- Phase
- Single Phase
- Input Voltage
- AC/DC 24 V
- Material
- Metal
- Connection Type
- Cable
- Angle of Rotation
- 95° (adjustable 30° to 95°)
- Position Indication
- Mechanical
- Manual Override
- Push button
- Cable Entry
- Prewired
- Degree of Protection
- IP54
- Control Signal
- DC 2...10 V, 4...20 mA, MP-Bus
- Torque
- 10 Nm
- Running Time Motor
- 150 s (90°)
- Housing Material
- Zinc-plated steel and plastic
- Ambient Storage Temperature
- -40°C to +80°C
- Gear Type
- Self-locking
- Feedback Signal
- DC 2...10 V
BELIMO NMV-D3-MP Damper Actuator Trade Information
- Minimum Order Quantity
- 1 Unit
- Delivery Time
- 5-7 Days
About BELIMO NMV-D3-MP Damper Actuator
| Structure | Damper Actuator |
| Valve Motion | Rotary Motion Valve |
| Model Name/Number | NMV-D3-MP Damper Actuator |
| Brand | BELIMO |
