Send InquiryBELIMO NF24-S Spring Return Actuators
Price 9650 INR/ Unit
MOQ : 1 Unit
BELIMO NF24-S Spring Return Actuators Specification
- Mounting Type
- Direct Coupled
- Efficiency
- High Efficiency Motor
- Insulation Material
- Class III insulation
- IP Rating
- IP54
- Feature
- Spring Return, Fail-Safe
- Shape
- Rectangular
- Humidity %
- < 95% RH non-condensing
- Overheating Protection
- Electronic Motor Cut-Off
- Connector Type
- Terminal Cable, Plug
- Surface Finish
- Powder Coated
- Operating Temperature
- 30C to +50C
- Product Type
- Spring Return Actuators
- Application
- Industrial
- Protection Level
- Double Insulated
- Frequency (MHz)
- 50/60 Hz
- Rated Voltage
- 24 V DC Volt (V)
- Energy Consumption
- 6.5 W (Running), 3 W (Holding)
- Output Type
- Rotary
- Color
- Orange
- Dimension (L*W*H)
- 199 x 80 x 74 mm
- Weight
- 3 Kilograms (kg)
- Input Voltage
- 24 V AC/DC
- Size
- 18 Nm torque
- Material
- Aluminum Alloy, ABS Plastic Housing
- Connection Type
- Cable, Connector
- Maximum Shaft Diameter
- 20 mm
- Spring Return Direction
- Clockwise or Counterclockwise (Selectable)
- Position Indication
- Mechanical
- Actuating Force
- 18 Nm
- Control Signal
- On/Off
- Running Time (Motor)
- 150 s
- Spring Return Time
- 20 s
- Ambient Humidity
- 5% to 95% RH non-condensing
- Ambient Temperature Range
- -30°C to +50°C
BELIMO NF24-S Spring Return Actuators Trade Information
- Minimum Order Quantity
- 1 Unit
- Delivery Time
- 5-7 Days
About BELIMO NF24-S Spring Return Actuators
| Actuator Type | Electric Actuator |
| Structure | Actuator |
| Voltage | 24 V DC |
| Model Name/Number | NF24-S |
| Brand | BELIMO |
| Torque | 7Nm |
| Weight | 3.0KG |
